manufacturer
Leonardo
configuration
Offshore
condition
Used
year
2017
time
299
helicopter location
Malaysia
listing ID
HT8829
Description
YOM November 2017
Total Time 299 hours/704 landings
Flight rules DP IFR
Registration FAA
Crew/passengers 2 crew/12 passengers
Empty weight circa 4,500 kgs
MTOW 7,000 kgs
Avionics phase 7
Highlights
•LHD warranty 1 year/500 hours
•Delivered with 4 years inspection performed
•Emergency flotation system and life rafts Aerazur
•Cargo hook provisions 2,200 kg/4,850 lbs
•Rescue hoist single Breeze provisions
•Soundproofing
•Anti vibration control system
•4 axis DAFCS, TCAS II, EGPWS
•Satcom Skytrack ISAT-200A, HEELS
•ADELT, HOMP, ADS-B out, CVR/FDR, HUMS
avionics
•Weather radar Primus 660 Honeywell
•Radar altimeter RT-300 x2
•4 axis DAFCS
•Flight director system x2
•GPS modue GNSS/SBAS with FPMS x2
•Mode S diversity transponder with ES ADS-B out
1,090 MHz
•CVR/FDR with ULB
•HUMS
•PFD x2
•MFD x2
•ESIS
•AHRS x2
•Flux valve x2
•Display controller x2
•Cursor control device x2
•Reversion control panel
•Display dimming control panel
•Stability augmentation system control panel
•Remote instrument controller x2
•Modular avionic unit x2
•Vehicle monitoring system x2
•Monitor warning system x2
•Aaural warning generator
•Central maintenance computer
•Provision for CVR/FDR data interface
•Pilot and co-pilot interphone control
•VHF radio x2
•VOR/LOC/GS/MB x2
•ADF
•DME
•MCDU x2
•ELT
•Flight guidance control
•Pilot and co-pilot digital audio panels
•Digital clock x2
•Magnetic compass
•OAT indicator
•Master warning lights x2
•Master caution lights x2
•Engine fire light x2
•Baggage compartment smoke detector light
•Electrical power connection for CVR/FDR x2
•TCAS II
•EGPWS
•Satcom Skytrack ISAT-200A
•ADELT
•HOMP
equipment
•Air conditioning system
•Cockpit tinted upper window
•Co-pilot hinged window (storm window)
•Approach plates chart holders with lights for pilot and co-pilot
•Rescue hoist single Breeze provisions
•Strobe lights on the winglets
•Cabin door external lighting LH and RH system
•110V power outlets in passenger cabin
•Cargo hook provisions 2,200 kg/4,850 lbs
•Main rotor blades high visibility painting
•Soundproofing
•Standard roof liners with dome lights
•Composite liners
•PA system with loudspeakers on standard ICS
•Fixed steps for passenger cabin access LH and RH
•Forced fan ventilation
•Bleed air heater and defroster with air noise suppression
•Cockpit air ventilation system
•Pilot headset hooks x2
•Baggage compartment cargo tie-down fittings
•Rotor brake
•Crew crashworthy seats
•Cockpit dome/storm light
•28 V DC cockpit/cabin power outlet
•Cockpit panel sun-glare shields
•Overhead cockpit windows sun shades
•Fluorescent emergency exit signs
•Cockpit map and data case
•Pilot and co-pilot flashlights
•First aid kit
•Maritime protection
•DC primary power generation
•DC external power receptacle
•Ni-Cd 44 Ah (20 cells) main battery
•Ni-Cd13 Ah auxiliary battery
•DC starter generator control unit x2
•Navigation light x3
•Anti-collision light
•External emergency landing light on the sponsons x2
•Retractable/rotating landing/taxing light x2
•Baggage compartment light x3
•Baggage compartment smoke sensor
•Magnetic chip detector x2
•Anti vibration control system
•ICS Cabin (12/15 Pax) rigid liners
•HEELS
•External tail video camera
•Emergency flotation system Aerazur
•Life rafts Aerazur
•Auxiliary transversal fuel tank 132 US gallon
